Screw compressor KOMPBERG® ZXF160

airelectricfixed

Product overview
The KOMPBERG® ZXF160 is an oil-free two-stage screw compressor, air-cooled and engineered for continuous industrial operation where oil-free compressed air is required. BERG Kompressoren manufactures and individually tests each unit to meet ISO 8573-1 CLASS 0 requirements. The ZXF160 pairs two-stage compression with direct-drive transmission to deliver stable performance and simplified maintenance.

Key features

• Oil-free two-stage screw compression
• Air-cooled design for site installation without external cooling circuit
• Direct-drive power transmission; nominal motor power 160 kW
• Tested to ISO 8573-1 CLASS 0 for oil-free air (manufacturer data)
• Factory-tested units with documented performance verification

Technical data (summary)
The main technical parameters and operational limits are listed below. Refer to the product technical data sheet for full tables and available options.

Technical specifications

• Model: KOMPBERG® ZXF160 (ZX series, two-stage, air-cooled)
• Operating overpressure: 8 / 10 bar
• Capacity at 8 bar: 25.7 m3/min
• Capacity at 10 bar: 22.5 m3/min
• Dimensions (L×W×H): 4000 × 2200 × 2200 mm
• Compressed air connection: G 3
• Weight: 5000 kg
• Ambient temperature range: +5 ÷ +40 °C
• Cooling air demand: 32500 m³/h
• Compressed air outlet temperature: approx. 10–15 °C above ambient
• Sound level L: 85 dB(A)
• Power transmission: direct drive
• Nominal motor power: 160 kW
• Nominal fan motor power: 11 kW
• Feed voltage: 400 V
• Recommended power feed cable: 3x150+PE (mm²)
• Protection fuse: 400 A
