Screw compressor KOMPBERG® ZXF75

airelectricstationary

Product information
Oil-free two-stage screw compressor KOMPBERG® ZXF75 for industrial compressed air installations, nominal motor power 75 kW.

Key advantages

• Two-stage oil-free screw design for contamination-free compressed air
• Low-noise and low-vibration construction suitable for industrial environments
• Compact layout for straightforward installation and commissioning
• SIEMENS electric motor and inverter supplied
• Advanced SIEMENS control and monitoring for process integration
• High-quality inlet/blowdown valve
• Zero-loss electronic drains

Notes
Air-cooled, two-stage oil-free screw compressor engineered for continuous industrial operation. Unit is tested and supplied with SIEMENS motor, inverter and advanced controller for monitoring and control.

Documents available

• Technical data sheet KOMPBERG® ZXF75
• SIEMENS inverter user manual
• Pre-start commissioning procedure for screw compressors
• Operation and maintenance manual for the oil-free screw compressor and controller
• 75 kW operation and maintenance manual
• PLC manual (electrical section) KOMPBERG® ZXF75
• Spare parts list and maintenance kits for ZXF75
• Safety data sheet PNEUMOIL SM46-TURBO OIL T46

Technical specifications

• Model: KOMPBERG® ZXF75
• Type: Oil-free two-stage screw compressor, air-cooled
• Delivery: 12 m3/min @ 8 bar; 9.7 m3/min @ 10 bar
• Operating pressure: 8 / 10 bar
• Nominal motor power: 75 kW
• Fan motor power: 4 kW
• Supply voltage: 400 V
• Dimensions (L x W x H): 2800 x 1600 x 2000 mm
• Weight: 3770 kg
• Noise level: 85 dB(A)
• Compressed air outlet: G 2
• Cooling air demand: 16500 m3/h
• Operating ambient temperature: +5 °C to +40 °C
• Compressed air temperature at outlet: approx. 10–15 °C above ambient
• Recommended power feed cable: 3x70+PE mm2
• Protection fuse: 160 A
• Product number / SKU: 1481110473
