Setting tool 2-701

Handheld insertion tool for non-soldering, non-screwing and non-stripping termination of data cabling; enables insertion and simultaneous cutting of wire ends. Designed for terminating data cables on outlets and patch panels and compatible with LSA-PLUS® series, RJ45 sockets and Highband.

Key features

• For UTP and STP cable conductors Ø 0.4–0.8 mm
• Enables soldering-, screwing- and stripping-free termination
• Press-in and cut-off in a single operation
• Material: synthetic body
• Length: 185 mm
• Weight: 62 g
• Compatibility: LSA-PLUS®, RJ45 sockets, Highband

Area of application
Insertion tool for termination of data cables on distribution strips, outlet boxes and patch panels. Intended for use where fast, tool-based insertion and simultaneous trimming of conductor ends is required, particularly in data outlet and patch-panel installations.

Technical description
Application tool for data, information and telecommunication cabling. Applicable to all LSA-PLUS® series as well as RJ45 sockets and Highband. Designed for connecting conductor diameters 0.35–0.9 mm and core diameters 0.7–2.6 mm.

Characteristics / technical specifications

• Denomination / model: LSA-Plus insertion tool
• Product code: 2-701
• Compatibility: all LSA-PLUS® series, RJ45 sockets, Highband
• Connecting conductor diameters: 0.35 - 0.9 mm
• Core diameters: 0.7 - 2.6 mm
• Intended use: termination of data cables on outlets and patch panels (non-soldering, non-screwing, non-stripping)
