Torx screwdriver bit set 4-970-A

Phillipsfor hexagonal-head screwsfor slotted screws

This 47-piece bit set includes two preset torque adapters (0.1 Nm and 0.2 Nm) for precision screwdriving, especially suited to electronics and mobile-phone repair. The adapters convert a 4 mm C4 bit and holder into a small torque tool with an audible click when the preset torque is reached.

Key features

• Preset torques: 0.1 Nm and 0.2 Nm; tolerance ±10% (factory certificate on request)
• Adapter Ø 8 mm, length 22 mm (without shank). Recommended max. 100 rpm with power tools
• Drive / bit shank: 4.0 mm hex; magnetic bit holder 4.0 mm
• Materials: stainless steel and high-grade tool steel; extension made of aluminum
• ESD handle dissipative (10^6 to 10^9 ohm)
• Supplied in a plastic case with foam insert; dimensions 175 x 160 x 45 mm; weight 410 g

Area of application
Turns a 4 mm C4 bit and holder into a precision torque tool. Adapters are primarily intended for manual use; when used with power tools, limit speed to 100 rpm to avoid frequent clicks. The audible click indicates the preset torque has been reached and prevents overtightening. When loosening screws, there is no torque unlocking due to the blocked core shaft (resulting in approx. 30% higher torque when loosening).

Technical description
Adapters are tested according to DIN EN ISO 6789 (hand-operated torque screwdriving tools) and guarantee ±10% tolerance for at least 20,000 clicks. The mechanism locks the ratchet in the bushing sleeve and comprises a hollow core shaft and a damping cylinder; when applied torque exceeds the preset value, the core shaft becomes inactive so no further increase in tension is transmitted to the screw.

General information
Torque adapters are suitable for electronic equipment, quick-change systems, robotic stations, aerospace, medical applications or any workstation where accurate low torque is required.

Content

• 4-971 torque adapter 0.1 Nm for 4 mm bits
• 4-972 torque adapter 0.2 Nm for 4 mm bits
• 6-340-3 C4 bit set 42 pcs, consisting of: Slotted 1.0-1.5-2.0-2.5-3.0; Cross PH000-PH00-PH0-PH1; Torx T3-T4-T5-T6-T7-T8-T9-T10-T15; Hex 0.9-1.3-1.5-2.0-2.5-3.0; Wrenches 2.5-3.0-3.5-4.0-4.5-5.0; Triangle 1.6-2.0-2.2-2.3; Square S0-S1; Pentalobe P2-P5-P6; SIM ejector; Tri-Point 0-1
• 6-340-2 bit extension for 4 mm (5/32 inch) hex bits
• 6-340-1 ESD bit holder dissipative for 4 mm (5/32 inch) hex bits
• 4-564 bit adapter 1/4 to 4 mm bits, length 42.5 mm

Technical specifications

• Product type: 47-piece bit set with torque adapters
• Preset torque adapters: 0.1 Nm and 0.2 Nm
• Tolerance: ±10% (DIN EN ISO 6789), tested ≥ 20,000 clicks
• Adapter diameter: Ø 8 mm; adapter length (without shank): 22 mm
• Drive / bit holder: 4.0 mm hex shank; magnetic bit holder 4.0 mm
• Materials: stainless steel and tool steel; extension: aluminum
• ESD handle resistance: 10^6 to 10^9 ohm
• Recommended max. speed with power tools: 100 rpm
• Case: plastic case with foam insert
• Case dimensions: 175 x 160 x 45 mm
• Weight (set): 410 g
