Vertical-shaft impact crusher VSI950

stationarysand productionvertical-axis

Product overview
The Borataş® VSI950 is a compact stationary vertical shaft impact (VSI) crusher designed to produce high-quality cubical aggregates and manufactured sand. Featuring a 900 mm open rotor and configurable crushing chamber, the VSI950 delivers consistent particle shape control and flexible operation for asphalt aggregate, concrete recycling, sand manufacturing and industrial minerals.

Specifications

• Rotor size: 900 mm
• Maximum feed size: 60 mm
• Capacity: 75 – 250 t/h
• Engine power options: 160 kW, 200 kW, 250 kW
• Weight: 13,500 kg

VSI950 key characteristics

• Open rotor design for optimized particle velocity and improved cubical product shape.
• Configurable chamber: rock-on-rock or rock-on-anvil modes to adapt to material and product targets.
• Adjustable rotor speed to fine-tune output gradation and shape.
• Compact heavy-duty frame with easy-access service doors for simplified maintenance.
• Energy-efficient operation via optimized rotor geometry and variable-speed control.

Standard features

• 900 mm open rotor
• Adjustable rotor speed
• Heavy-duty steel construction
• Rock-on-rock and rock-on-anvil compatibility
• Access doors for easy maintenance
• Replaceable wear parts

Optional features

• Dust suppression system
• Automatic lubrication unit
• Vibration monitoring sensors
• Anvil ring configuration

Technical specifications

• Model: VSI950
• Rotor size: 900 mm
• Maximum feed size: 60 mm
• Capacity range: 75 – 250 t/h
• Engine power options: 160 kW, 200 kW, 250 kW
• Machine weight: 13,500 kg
• Open rotor design with configurable chamber (rock-on-rock or rock-on-anvil)
• Adjustable rotor speed for product shape control
• Heavy-duty steel frame with access/service doors
• Replaceable wear parts; optional dust suppression, auto lubrication and vibration monitoring
