DC solid state relay SMQR9623410

AC24VDC24VAC

Overview
The SMQR9 four-leg solid state relays integrate four independent SSR channels in a single sightpac® 45 mm package. Models feature push-in spring terminals for fast, tool-free wiring and are intended for AC-1 resistive loads.

Advantages

• Tool-free push-in connection for simplified installation
• Fast wiring in confined spaces
• Secure electrical connection reducing installation time
• Compact sightpac® package saves panel space

Product variant (example)
Part number: SMQR9623410
Short description: SSR PUSH IN 4X25A / 24-660VAC / TVS / 4 CTRL 10-30VDC / LED
Max. switching current per phase @40°C AC-1: 25 A
Max. switching voltage: 24-660 VAC
Control voltage: 10-30 VDC
Functionality: Four-leg SSR with push-in spring terminals - Zero-cross switching - output protection - LED indicator
Series: SMQR9
Standards: CE - UL (cURus) - UKCA
Availability example: In stock 70 pcs
Public unit price (excl. Taxes) example: 246.82 EUR

Technical specifications

• Package: sightpac® 45 mm width
• Configuration: Four relays in one (four-leg SSR)
• Terminals: Quick-connect / push-in spring terminals
• Intended loads: AC-1 resistive loads
• Max. switching current per phase (example variant): 25 A @ 40°C (AC-1)
• Max. switching voltage: 24-660 VAC
• Control voltage range: 10-30 VDC
• Protection / features: Zero-cross switching, output protection, TVS, LED indicator
• Standards / Approvals: CE, UL (cURus), UKCA
• Series name: SMQR9
