Ball valve leverpneumaticelectrically-actuated
Add to favorites
Compare this product
Characteristics
- Type
- ball
- Operation
- lever, pneumatic, electrically-actuated, hydraulically-operated
- Media
- for water, for chemical products
- Body
- flange, 1-piece
- Applications
- for the chemical industry, for the petroleum industry, for shipbuilding, for water treatment, power line
- Other characteristics
- standard, anti-static
- DN
8 in
- Pressure
Min.: 16 bar
(232.1 psi)Max.: 420 bar
(6,091.6 psi)- Temperature
Min.: -29 °C
(-20 °F)Max.: 200 °C
(392 °F)
Description
One-piece Ball Valve manufacturer: ASTM A216 WCB Ball Valves, 8 Inch, Class 600 LB, API 6D, RF, One-piece Valve Body, Lever, Gearbox, Electric Actuator.
Valve Description
Design Standard: API 6D.
Body Material: ASTM A216 WCB.
Pressure: Class 600 LB.
End Connection: RF.
Face to Face: ASME B16.10.
Test and Inspection: API 598.
Product Range
Operation: Lever, Gearbox, Electric, Pneumatic, Electro Hydraulic Actuator, Gas Over Oil Actuator.
Features: One-piece Type Body, Emergency Sealant Injection, Low Emission Packing, Fire Safe, Anti-Static and Anti-Blowout Stem, Valve Seat Function DBB, Optional Extended Bonnet, Cavity Pressure Self-Relief.
