DC/DC converter controller 2 A, 4.75 - 18 V | AP65200

The AP65200 is a 340kHz switching frequency external compensated synchronous DC/DC buck converter. It has integrated low RDSON high and low side MOSFETs. The AP65200 enables continues load current of up to 2A with efficiency as high as 95%. The AP65200 implements an automatic custom light load efficiency improvement algorithm. The AP65200 features current mode control operation, which enables fast transient response times and easy loop stabilization. The AP65200 simplifies board layout and reduces space requirements with its high level of integration and minimal need for external components, making it ideal for distributed power architectures. The AP65200 is available in a standard Green SO-8 package and is RoHS compliant. Features and Benefits VIN 4.75V to 18V 2A Continuous Output Current, 3A Peak Efficiency Up to 95% Automated Light Load improvement VOUT Adjustable to 0.925 to 16V 340kHz Switching Frequency External Programmable Soft-Start Enable Pin OCP and Thermal Protection Totally Lead-Free & Fully RoHS Compliant Halogen and Antimony Free. Green Device
