Analog I/O module DMB 96400 B

Modbus RTU4-channel2 analog outputs

4 Fully Isolated Analog I/O Channels, Modbus RTU Processing of 4 industrial standard signals individually configurable as current or voltage signal 4 galvanic isolated I/O ports protection against erroneous measurements due to parasitic voltages or ground loops Protective 5 port separation up to 300 V AC/DC, Test voltage 3 kV Fast signal acquisition high measuring rate, short processing times In-Rail-Bus connector for Modbus and Power Supply allows fast and economical installation Freely scalable up to 247 DRAGO Module in one Modbus segment Extremely slim design 6.2 mm slim housing for a simple and space saving DIN rail mounting Made in Germany 5 Years Warranty The Modbus 4 Channel Analog Module provides four fully isolated, independently configurable channels. Two inputs can be configured as current or voltage inputs. In addition, these can be configured as digital inputs or digital outputs (open collector). Two outputs can be configured as current or voltage outputs. In addition, these can be configured as digital outputs (active logic 0/10 V). All parameters can be set via the Modbus RTU interface and via a programming socket behind the front panel. A free PC configuration software also offers extended setting options and extensive diagnostic functions during operation. A subset of the most common settings is also available via DIP switches. The 5 port isolation ensures reliable decoupling of the channels from each other and from the processing circuit and the power supply. Power supply and Modbus RTU are connected via the rearmounted In-Rail-Bus connection (see Accessories)
