High-speed document scanner DS-6500

colorstationaryautomated

Overview
This A4 document scanner is designed for businesses requiring reliable, high-throughput document capture for archiving and distribution. The Epson WorkForce DS-6500 offers one-pass duplex scanning, up to 25 pages per minute, and a 100-sheet automatic document feeder. It includes ultrasonic double-feed detection and Document Capture Pro for direct integration with document management systems. ReadyScan LED minimizes warm-up and power use; the device is ENERGY STAR-qualified and receives security updates for 7 years under UK Product Security requirements.

Key features

• One-pass duplex scanning: both sides in a single pass
• Scan speed: up to 25 ppm / 50 ipm (200/300 dpi)
• 100-sheet ADF for batch scanning
• Double-feed detection: ultrasonic sensor
• Energy-efficient ReadyScan LED; ENERGY STAR-qualified
• Document Capture Pro: scan to email, FTP, SharePoint, network folders and more

What is in the box?

• AC adapter
• Main unit
• Setup guide
• Software (CD)
• USB cable
• User manual (CD)
• Warranty document

Technical specifications

• Scanner type: Flatbed with single-pass dual ADF
• Optical resolution: 1,200 x 1,200 DPI
• ADF document size: min 100 x 148 mm, max 2,159 x 1,016 mm
• Supported formats: A4, A5, A6, B5, Letter, Legal, Executive
• Color depth: Input 48-bit / Output 24-bit
• Scanning speed: 25 ppm (mono & color) = 50 ipm (duplex) at 200/300 dpi
• Paper weight (auto): 50–128 g/m²
• Daily duty cycle / scanning volume: 3,000 pages
• Output formats: JPEG, TIFF, multi-TIFF, PDF, searchable PDF, PDF/A, secure PDF
• Compression: Hardware JPEG, TIFF (JPEG, CCITT G4, LZW), PDF compression
• Connectivity: USB 2.0; optional Ethernet (1000Base-T/100Base-TX/10Base-T)
• Drivers: TWAIN, WIA, ISIS, SANE (Linux), ICA (Mac)
• Included software: Epson Document Capture Pro, Epson Scan, Epson Event Manager
• Dimensions (W×D×H): 495 × 360 × 217 mm; Weight: 9.8 kg
• Operating temperature/humidity: 5°–35° C; 10%–80% RH
• Security & support: UK Product Security compliance, 7 years of security updates
