Handheld bending machine MN092

electrictubedigital

Description
The MN092 is a compact, portable rotary draw tube bender designed for fast, on-site bending tasks. Suited for maintenance work in shipyards, construction sites and service workshops. Standard steel tube capacity: 27 x 2.3 mm.

Features

• Capacity on standard steel tube: 27 x 2.3 mm
• Capacity on gas tube: 3/4" x 2.9 mm
• Bend radii: from R36 to R190 mm
• Simple microprocessor control with digital display of bending and return angles
• Programmable up to three bend angles with individual springback compensation values
• Bend angle monitored with digital display
• Counterdie jaw screw feeding system
• Quick and easy tool change system (Ercolina® patent)
• Standard tripod for stable operation
• Additional free-bend operating mode

Other available models (table)
MODELS | DESCRIPTION | POWER SUPPLY
MN092M | MiniBender MN092M | Single-phase

Technical specifications

• Bending module: 0.7 cm³
• Minimum external diameter: 5 mm
• Maximum external diameter: 27 mm
• Maximum bend capacity: Ø 27 x 2.3 mm
• Minimum bend radius (CLR): 10 mm
• Maximum bend radius (CLR): 190 mm
• Installed power: 800 W
• Bending speed: 2 rpm
• Dimensions (L x W x H): 200 x 105 x 570 mm
• Weight: 15 kg
