Manual strap tensioner CT series

for steel straps

TENSIONERS CTT/CTG SERIES Tensioners CTT/CTG series are used to tension the plastic and fabric strap and perform the ligation of pallets and packages through the use of metal buckles or welding. Binding with metal buckle (strapping fabric) The operator wraps the product with the strap, puts the two ends through the buckle and places them into the strapping tool. The first end is locked with the brake while the second is placed under the cutter and inside the tension roller. Increasing the tension of the strap, the buckle keeps the tension. After reaching the desired tension, the strap is cut automatically by the tensioning device. Binding by welding (plastic fabric) The strapping by means of welding is used with polyester strap or polypropylene and is done in the same way as the previous strapping but without the use of the buckle. At the end of the tension, a welder is used to lock the strap in tension. The welded strap is then cut from the strap tightener. In some cases, you can also use a metal seal, closing it by means of special pincers. The tensioners are available in the following models: MODEL | Max strap width | Tensioning max. | Tensioner weight CTT 20 | 20 mm | 50-450 daN | 1.2 kg CTG 25 | 25 mm | 50-550 daN | 1.8 kg CTT 32 | 32 mm | 50-550 daN | 2.1 kg CTG 40 | 40 mm | 200-750 daN | 2.2 kg CTT 50 | 50 mm | 200-750 daN | 2.3 kg CTT 50R | 50 mm | 200-750 daN | 3 kg The holding capacity of strap depends on material type and on strap of choice. OPTIONAL - Strapping trolley For handling and unwinding of the strap reel it is appropriate to use the special trolley. In this way you can avoid problems when strapping band is carried out incorrectly. - Welder for strapping The welder is used in case you do not use metal buckles. - Protective corners The plastic and cardboard protective corners are used on products still to be strapped, so that the strapping tension does not damage the corners of fragile products. Product Short Description: Idlers for tensioning and cutting of plastic and textile polyester strap from 20 to 50 mm. - Available models: CTT 20, CTG 25, CTT 32, CTT 32-CT, CTG 40, CTT 50, CTT 50R - Prices (excl. VAT): 150.00 €, 320.00 €, 375.00 €, 750.00 €, 550.00 €, 770.00 € (depending on model) Technical Specifications: - For plastic and textile polyester straps - Strap width: 20 to 50 mm (depending on model) - Tensioning max: 50-750 daN (depending on model) - Tensioner weight: 1.2 to 3 kg (depending on model) - Binding by metal buckle or welding - Optional accessories: strapping trolley, welder, protective corners
