Edge loading ramp FPH series

vehiclegroundindustrial

LOADING RAMPS SERIES FPH190-220The ramps of the FPH190-220 series are perfect equipment for loading heavy vehicles, designed to ensure maximum resistance and safety in the loading and unloading operations of high-tonnage vehicles. Ideal for use in the agricultural and earthmoving sectors, these ramps are the perfect solution for use with heavy excavators, large tractors, combine harvesters and other agricultural or industrial vehicles.Built with high-resistance materials and reinforced structural profiles, they offer a load capacity of up to 12,000 kg, ensuring solidity even in the most extreme working conditions. The available length of up to 5,000 mm allows a controlled slope suitable for high containers and platforms, ensuring safety even when manoeuvring tracked vehicles.The ramps are available both in the version with a lateral safety edge with a height of 43 mm (for the FPH190 models), and 50 mm (for the FPH220 models), useful for preventing lateral slipping, and in the version without an edge.The FPH220 version has a maximum internal width of 500 mm, but on request a version with an increased width of 550 mm is also available, ideal for those who need a larger transit area.All models are supplied with a non-slip surface with steps, designed to ensure maximum grip during use.CHOOSING THE LENGTH:The choice of length is a fundamental aspect to ensure safe use of the ramp, the latter is calculated based on various factors:- Loading height: The distance between the ground and the point where the ramp ends (usually the cargo area of ​​a van). The greater this height, the greater the length of the ramp must be to avoid excessively steep inclinations.- Ramp inclination: it is advisable to maintain a maximum slope between 20% and 30% depending on the type of load.- Product weight: another fundamental aspect is the weight of the vehicle/equipment to be loaded. Based on this, it is good to consider that the shorter the ramp, the greater its capacity will be, but at the same time the greater the inclination that the latter will assume.Based on this we can indicatively determine that:- In the presence of a height of 95 cm it is recommended to use a ramp with a length of 3500 mm- In the presence of a height of 110 cm it is recommended to use a ramp with a length of 4000 mm- In the presence of a height of 125 cm it is recommended to use a ramp with a length of 4500 mm- In the presence of a height of 145 cm it is recommended to use a ramp with a length of 5000 mmTECHNICAL CHARACTERISTICS FPH190-220MODELStructureCapacity (wheelbase1500 mm)Capacity (wheelbase 1750 mm)Capacity (wheelbase2000 mm)LengthInternal widthExternal widthWeight per coupleFPH190-35SNo border9700 Kg10450 Kg10450 Kg3500 mm500 mm610 mm140 KgFPH190-40SNo border7700 Kg8580 Kg9650 Kg4000 mm500 mm610 mm163 KgFPH190-45SNo border6400 Kg6980 Kg7680 Kg4500 mm500 mm610 mm180 KgFPH190-50SNo border5450 Kg5870 Kg6360 Kg5000 mm500 mm610 mm200 KgFPH190-35BWith border9700 Kg10450 Kg10450 Kg3500 mm500 mm595 mm140 KgFPH190-40BWith border7700 Kg8580 Kg9650 Kg4000 mm500 mm595 mm160 KgFPH190-45BWith border6400 Kg6980 Kg7680 Kg 4500 mm 500 mm595 mm174 KgFPH190-50BWith border5450 Kg5870 Kg6360 Kg5000 mm500 mm595 mm196 KgFPH220-40SNo border1200 Kg12000 Kg12000 Kg4000 mm500 mm620 mm173 KgFPH220-45SNo border9600 Kg12000 Kg12000 Kg4500 mm500 mm620 mm194 KgFPH220-50SNo border8175 Kg8800 Kg9535 Kg5000 mm500 mm620 mm216 KgFPH220-40BWith border12000 Kg12000 Kg12000 Kg4000 mm500 mm580 mm167 KgFPH220-45BWith border9600 Kg12000 Kg12000 Kg4500 mm500 mm580 mm188 KgFPH220-50BWith border8175 Kg8800 Kg9535 Kg5000 mm500 mm580 mm210 KgThe ramps are supplied complete with hole but without anchoring accessories, it will be the customer's responsibility to equip themselves with the appropriate fixing systems based on their operational needs.Load capacity: up to 12,000 kgLength: up to 5,000 mmInternal width: 500 mm (550 mm on request for FPH220)Edge height: 43 mm (FPH190), 50 mm (FPH220)Non-slip surface with stepsAvailable with or without lateral safety edgeSupplied with hole for fixing (no anchoring accessories included)
