Pallet lift FP SDJ 1010

MANUAL PALLET ELEVATOR MOD. FP SDJ 1010 Pallet lift with hydraulic pedal pump and rudder (the pedal is used to lift limited weights), steel structure with rounded fork tips, nylon directional wheels with parking brake and double front rollers, forks with fixed width. ATTENTION: all lifts are shipped already assembled, tested one by one before being professionally packaged and complete with CE certification. MODEL: FP SDJ 1010 Load: Kg. 1000 Maximum fork height: mm. 1000 Minimum fork height: mm. 90 Total fork width: mm. 550 Single fork width: mm. 170 Fork length: mm. 1100 Weight: Kg. 185 Overall dimensions: mm. 1640x740x1490 h. FPSDJ elevators are very practical and robust elevators, recommended in environments with smooth flooring (e.g. warehouses) where occasional and non-continuous lifting of pallets does not justify the purchase of a battery-powered model. The structure and operation are similar to those of a standard pallet truck. It is possible to lift the load either via the rudder or the pedal. With each pumping stroke the forks are raised by approximately 3 cm. Descent occurs by pressing the lever on the rudder. Controlled descent and is at a safe speed. The load must be evenly distributed on the forks. As with all lifting equipment, attention must be paid to the safety diagram. Depending on the size and characteristics of the lift, the capacity decreases as the height or distance from the center of gravity increases. They are very robust and mechanically simple products. It's rare that they have any problems. Just in case, we have all the spare parts in stock. All models are CE certified and are supplied with a specific use and maintenance manual. A specific license is not required to use the lift. The operator must be trained and informed. The instructions in the manual must be read and followed. - Model: FP SDJ 1010 - Load capacity: 1000 kg - Maximum fork height: 1000 mm - Minimum fork height: 90 mm - Total fork width: 550 mm - Single fork width: 170 mm - Fork length: 1100 mm - Weight: 185 kg - Overall dimensions: 1640x740x1490 mm (height) - Hydraulic pedal pump and rudder - Steel structure with rounded fork tips - Nylon directional wheels with parking brake - Double front rollers - Forks with fixed width - CE certified
