Planetary mixer Double Planetary Mixer

batchsolid/liquidfor coatings

Working Principle: The rotating planetary frame of the double planetary mixer drives the mixing shaft and the dispersion shaft to revolve around the container axis and perform rotational motion. It exerts strong shearing and kneading forces on the materials at high speed, so that the materials are dispersed and mixed evenly. The scraper installed on the planetary frame is close to the cylinder wall and continuously scrapes the material off the cylinder wall. The inner wall of the cylinder is precisely lathe-machined and mirror-polished to ensure that the scraper can remove all the materials adhering to the container wall without leaving any residue. The blades can also be equipped with scrapers to scrape off the bottom materials to ensure that there is no mixing dead corner and the mixing effect is good. About Double Planetary Mixer: - Material Viscosity: ≤ 10,000,000 cps - Production Capacity: 5L-2200L - Application Industries: Applicable to the dispersion and mixing of materials in coatings, putties, adhesives, energy, electronics, medicine, cosmetics, food and other industries. - Applicable Materials: Battery slurry, solder paste, ceramic slurry, silicone ink, sealant, structural adhesive, ointment and other slurries with a viscosity of less than 10,000,000cps and a solid content of less than 90%. Advantages of Double Planetary Mixer: - High Mixing Efficiency and Wide Application Range - Easy and Safe to Operate - No Dead Corner in Mixing - Strong Non-standard Technical Specifications / Features: - Material viscosity: ≤ 10,000,000 cps - Production capacity: 5L-2200L - Application industries: coatings, putties, adhesives, energy, electronics, medicine, cosmetics, food, etc. - Applicable materials: battery slurry, solder paste, ceramic slurry, silicone ink, sealant, structural adhesive, ointment, and other slurries with viscosity < 10,000,000cps and solid content < 90% - Mixing principle: planetary stirring with dynamic stirring characteristics - Mixing effect: efficient material mixing and dispersing - Customizable options: explosion-proof, vacuum, heating/cooling, PLC control, material (SS304, SS316, etc.)
