Axial condenser CPN series

air-cooledsteelprocess

Air cooled condensers with axial single phase fan motors of diameter 300 and 400 mm. They can be used as remote condensers for small or medium cold installations and they can also be placed in condensing units. CHARACTERISTICS External rotor fan motors, single phase 230V/50Hz, IP-44 with thermal protection. The fact of being single phase allows their easy speed regulation for condensation control. Casing of galvanized and coated steel in white polyester colour RAL-9002 with high corrosion resistance. With galvanized steel supports for anchoring to the floor. SPECIFIC OPTIONS OF THIS RANGE Special fan motor single phase 230V/60Hz or three phase from 230V to 460V and from 50 to 60Hz. All models can be supplied in a double version, with two rows of fans, in a single unit, with single inlet and outlet headers.
