Water filter KIT PETRO-PIT® 401

for hydrocarbonswith cartridgePVC

Overview The PETRO-PIT® 401 filtration kit enables fast, straightforward installation of the PETRO-PIT-401 filter and its PFC-44 prefilter on retention basins and pits. Its self-locking mechanism traps harmful hydrocarbons and prevents soil contamination. The oleophilic and hydrophobic polymer component permanently retains hydrocarbons while allowing filtered rainwater to pass.

Kit contents

• 1 stainless-steel 90° elbow, 1.5 in female threaded outlet for the retention unit
• 1 stainless-steel 1.5 in quarter-turn valve
• 1 PFC-44 prefilter
• 1 PETRO-PIT-401 filter cartridge for non-specific hydrocarbons
• 1 roll of PTFE tape

Technology SPI® technology: the KIT PETRO-PIT® range is available in complete filtration systems matched to the fluid to be treated. The self-locking system confines hydrocarbons, and the oleophilic/hydrophobic polymer component permanently traps oils and hydrocarbons while ensuring passage of filtered rainwater.

Main features

• Rigid PVC construction treated for UV resistance to ensure durability
• Oleophilic and hydrophobic polymer component: permanently traps hydrocarbons
• Nominal operating temperature: -60° to +80°C
• Sealing by a compression O-ring guaranteeing full filtration capability
• Approximate filtered flow rate: 3 to 5 L/min
• Approximate saturation capacity: 1 L
• Recommended replacement: every 1 to 3 years depending on operating conditions
• Easy installation and maintenance: screw-in cartridge, outlet designed for valve and prefilter; maintenance in dry area
• Customisable to required flow and adaptable to ball valves, drains and wall penetrations

Applications

• Fire-retention basins and modular solutions installed under transformers (ERT®, TRT®, ERT-MODULO®, TRT-MODULO®)
• Temporary installations containing dielectric oils or hydrocarbons, including flexible TRFLEX® retention solutions
• Outdoor substations, photovoltaic skids and BESS platforms exposed to hydrocarbon pollution risk

Technical specifications

• Material: rigid PVC
• Operating conditions: Outdoor, Indoor
• Filtration: Dielectric oils, Hydrocarbons
• Approx. filtered flow rate: 3 to 5 L/min
• Approx. saturation: 1 L
• Nominal operating temperature: -60° to +80°C
• Recommended cartridge replacement: every 1 to 3 years depending on conditions
• SKU (product reference displayed): KIT PIT-410-1
