Elastomer coupling MKA-S seriesmetal bellowsstainless steelshaft
Add to favorites
Compare this product
Characteristics
- Type
- elastomer
- Construction
- metal bellows, stainless steel
- Product applications
- shaft
- Performance
- backlash-free
- Other characteristics
- torque
- Torque
Max.: 500 Nm
(368.781075 ft.lb)Min.: 15 Nm
(11.063432 ft.lb)
Description
MKA-S is the weight-optimised metal bellows coupling with aluminium clamping hubs. With only one clamping screw per hub it is very easy to install. The stable connection between the stainless steel metal bellows and the aluminium clamping hubs as well as the torsionally stiff metal bellows guarantee absolute freedom from backlash. Suitable for applications from 15 to 500Nm.
Shaft diameter up to 75 mm
clamping hub made of aluminium, easy to install
Characteristics
Clamping hub made of high-strength aluminium
Backlash-free torque transmission
Small installation space
Easy to install
Maintenance-free
High temperature resistance (150°C)
Very low moment of inertia
Ideal for servo motors
Low restore forces on bearing points
