Venturi flow meter Subsea-MPFM

for liquidsfor gasstainless steel

Haimo Subsea Multiphase Flow Meter (Subsea-MPFM) is a new product developed specifically for installation either directly on a production tree or on a in a subsea manifold on the sea bed. It has a very compact design for installation and retrieval using remotely operated vehicles (ROV), and new technologies for long term performance under harsh pressure, temperature, corrosion, undercurrent forces at water depths of more than 1000 meters. Haimo Subsea Multiphase Flow Meter (Subsea-MPFM) is developed based on Haimo's existing patented topside MPFM with added new technologies to insure accurate and reliable multiphase flow measurements for more than 20 years under the subsea harsh environments including high inside and outside pressures, low temperature, undercurrent shock load and vibration, and corrosion from seawater. The measurements are based the combination of dual-energy gamma ray meter and venturi mass flow meter, capable of handling oil and gas well flows up to 100% Gas Volume Fraction (GVF). The Subsea-MPFM provides real-time multiphase flow rates at standard conditions, together with inline pressure and temperature. Haimo Subsea-MPFM is constructed with materials that can stand the corrosive environment at the sea bed and corrosion from the production flow, and equipped with redundant components for double assurance. With a compact design, the Subsea-MPFM can be installed both directly on the wellhead for single well measurement or on a manifold for multiple well measurements.
