Pipe scraper TPS8

Rotary PE Pipe Peeler is a manual scraper designed to remove the oxidized layer from PE pipes and prepare surfaces for electro-fusion welding. The tool provides even, repeatable scraping with a retractable blade rod and an adjustable support frame for stable operation.

Key features

• Purpose: removal of oxidized/contaminated surface layer on PE pipes prior to electro-fusion welding.
• Operation: fully manual operation with simple, serviceable design.
• Construction: adjustable support frame covering full working ranges and a handle with fixed blade; freely retractable blade rod for servicing and blade replacement.
• Blade design: long-life blade with groove function; cutting points arranged in circular rows to avoid damage to the pipe surface.
• Performance: internal support structure ensures only the blade rod moves on the pipe surface, enabling smooth, jam-free scraping and consistent results.
• Result: clean, even scraped surface suitable for electro-fusion; repeatable scraping as required.

Applications

• Surface preparation of PE pipes before electro-fusion welding and other joining operations.

Models and technical data

• Series: TPS (Brand: MM-Tech)
• Models and data:
  • TPS8 — Working range (ID): 61–172 mm; OD: 75–200 mm; Scraping width: 129 mm; Weight: 2.8 kg.
  • TPS16 — Working range (ID): 130–391 mm; OD: 137–426 mm; Scraping width: 150 mm; Weight: 5.5 kg.
  • TPS24 — OD: 63–500 mm; Scraping width: 175 mm; Weight: 4.2 kg.
  • TPS32 — OD: 63–800 mm; Scraping width: 255 mm; Weight: 5.2 kg.

Specifications

• Material compatibility: PE (polyethylene) pipes.
• Operation mode: manual.
• Design features: adjustable support frame, fixed-blade handle, retractable blade rod.
• Blade characteristics: grooved blade for extended life; circular cutting-point layout to protect pipe integrity.
• Use case: continuous, regular scraping and trimming of plastic pipes to achieve welding-ready surfaces.
