Plasma cutting torch Duramax® Lock

roboticfor machinesmanual

Overview: Duramax® Lock torches have the ruggedness and reliability of the original Duramax torches. They support handheld and mechanized cutting of a wide range of metal thicknesses and offer enhanced gouging and marking capabilities. Duramax Lock torches are available with an extensive array of specialty consumable options for applications such as gouging, fine feature cutting, extended reach cutting, and flush cutting.

Features:

• Trigger lockout switch helps prevent accidental firing.
• Torch disable switch feature allows faster, easier changeout of consumables.
• SpringStart™ electrode technology for more reliable arc-starting (eliminates moving parts in the torch).

Applications:

• Drag cutting — For dragging the torch directly across the work piece.
• Extended reach cutting — For cutting at extended reach to access difficult areas.
• Extended reach gouging — For improved visibility and accessibility in confined spaces.
• Fine feature cutting — For cutting small, detailed features.
• Flush cutting — For cutting flush to base materials.
• Marking — For scoring and indicating part identification, hole or weld locations.
• Max control gouging — For precise metal removal, shallower gouge profiles and light metal washing.
• Max removal gouging — For aggressive metal removal and deep gouge profiles.
• Mechanized cutting — For portable automation and table cutting.
• Precision gouging — For spot and tack weld removal at very low output currents (<25 A).

Benefits:

• More reliable arc-starting via SpringStart™ electrode technology.
• Hand torches: Duramax® Lock 75° and 15° models suited for gouging, fine feature cutting, extended reach cutting, and flush cutting; 75° ergonomic design for normal cutting; 15° directs heat away from operator for heavy gouging and overhead or hard-to-reach cutting.
• Machine jobs: Duramax Lock full-length machine torch compatible with a wide variety of CNC cutting tables, track cutters, and pipe-cutters.

Cartridge adapter (compatibility):
System | Torch type | Adapter part number
Powermax45® XP | Duramax® Lock hand, machine, and robotic | 428951
Powermax65® | Duramax hand, machine, and robotic | 428951
Powermax85® | Duramax hand, machine, and robotic | 428951
Powermax105® | Duramax hand, machine, and robotic | 428951

Hypertherm cartridges — selected processes and cartridge part numbers:
Drag cutting / FineCut (hand) processes:
105 A — 428937
85 A — 428935
65 A — 428931
45 A — 428927 (mechanized/drag variants exist)
FineCut hand cutting — 428928

Mechanized and FineCut (machine) processes:
105 A — 428936
85 A — 428934
65 A — 428930
45 A — 428925
FineCut mechanized cutting — 428926

Max removal / Max control gouging cartridges:
Max removal gouging 105 A — 428938
Max removal gouging 45–85 A — 428932
Max control gouging 105 A — 428939
Max control gouging 45–85 A — 428933

Replaces / standard consumable stack-ups (selected references):
Shield | Retaining cap | Nozzle | Electrode | Swirl ring
220992 | 220854 | 220990 | 220842 | 220994
220818 (shield stack for some amperages) | 220854 (retaining cap) | 220990 (nozzle) | 220842 or 220777 (electrode variants, CopperPlus®) | 220994 (swirl ring)
Other replacement references shown on product page include 220931, 220930, 220947 and related retaining/deflector parts for various stack-ups.

Accessory / upgrade notes:

• Cartridge torch adapter converts existing Duramax® Lock torches to the Hypertherm cartridge consumable platform (adapter part number 428951).
• Hypertherm cartridge platform provides single-piece cartridges optimized by process and amperage to simplify parts and ensure performance for cutting and gouging.

Caractéristiques / spécifications techniques:

• Product code / internal tag: DURAMAX LOCK TORCHES
• Denomination commerciale (model/series): Duramax® Lock
• Marque: Hypertherm
• Torch types available: Hand (75°), Hand (15°), Full-length machine torch; also robotic variants supported.
• Compatible systems: Powermax45® XP, Powermax65®, Powermax85®, Powermax105® (adapter compatibility listed).
• Cartridge adapter part number: 428951 (enables cartridge consumable platform).
• Key consumable/process part numbers (examples): 428937, 428935, 428931, 428928, 428936, 428934, 428930, 428925, 428926, 428938, 428932, 428939, 428933.
• Selected legacy consumable references replaced by cartridge platform or listed stack-ups: 220992, 220854, 220990, 220842, 220994, 220818, 220816, 220819, 220857, 220941, 220931, 220930, 220947.
• Image assets on product page: multiple product images (example filenames duramax-lock-torches-313.jpg, duramax-lock-torches-314.jpg, duramax-lock-torches-312.jpg).
• Tag new product: no explicit “new” badge for the main product on the product title.
