4-wheel forklift J10-18XD
electricride-onhandling

4-wheel forklift - J10-18XD - HYSTER - electric / ride-on / handling
4-wheel forklift - J10-18XD - HYSTER - electric / ride-on / handling
Add to favorites
Compare this product

Characteristics

Motor type
electric
Operator
ride-on
Applications
handling
Other characteristics
4-wheel, high-performance, heavy-duty
Carrying capacity

Max.: 18,000 kg
(39,683.2 lb)

Min.: 10,000 kg
(22,046.2 lb)

Lifting height

Max.: 4,925 mm
(193.9 in)

Min.: 4,494 mm
(176.93 in)

Overall width

2,490 mm, 2,541 mm
(98 in, 100 in)

Overall length

Max.: 8,056 mm
(317.2 in)

Min.: 5,724 mm
(225.4 in)

Load center distance

600 mm, 750 mm, 900 mm, 1,200 mm
(23.6 in, 29.5 in, 35.4 in, 47.2 in)

Weight without load

Max.: 23,940 kg
(52,778.7 lb)

Min.: 14,670 kg
(32,341.8 lb)

Axle loading with maximum load front

Max.: 37,727 kg
(83,173.8 lb)

Min.: 23,421 kg
(51,634.5 lb)

Axle loading with maximum load rear

Max.: 3,410 kg
(7,517.8 lb)

Min.: 1,748 kg
(3,853.7 lb)

Axle loading without load front

Max.: 10,592 kg
(23,351.4 lb)

Min.: 7,820 kg
(17,240.1 lb)

Axle loading without load rear

Max.: 13,442 kg
(29,634.5 lb)

Min.: 6,850 kg
(15,101.7 lb)

Track width front

1,842 mm, 1,844 mm
(72.5 in, 72.6 in)

Track width rear

2,018 mm, 2,020 mm
(79.4 in, 79.5 in)

Height of mast when lowered

4,008 mm, 4,135 mm, 4,193 mm
(157.8 in, 162.8 in, 165.1 in)

Overall height with mast raised

6,255 mm, 6,597 mm, 6,648 mm
(246.3 in, 259.7 in, 261.7 in)

Height to top of overhead guard

Max.: 3,259 mm
(128.3 in)

Min.: 3,055 mm
(120.3 in)

Seat height

1,875 mm, 1,903 mm
(73.8 in, 74.9 in)

Tow couplig height

661 mm, 689 mm
(26 in, 27.1 in)

Length to fork face

Max.: 5,616 mm
(221.1 in)

Min.: 4,504 mm
(177.3 in)

Fork carriage width

2,396 mm, 2,496 mm, 2,540 mm
(94.3 in, 98.3 in, 100 in)

Ground clearance under mast with load

225 mm, 245 mm, 253 mm
(8.9 in, 9.6 in, 10 in)

Ground clearance at center of wheelbase with load

313 mm, 341 mm
(12.3 in, 13.4 in)

Turning circle radius

4,111 mm, 4,584 mm, 5,200 mm
(161.9 in, 180.5 in, 204.7 in)

Travel speed

25 km/h
(15.5 mph)

Lifting speed

Max.: 0.59 m/s
(1.936 ft/s)

Min.: 0.37 m/s
(1.214 ft/s)

Lowering speed

Max.: 0.56 m/s
(1.837 ft/s)

Min.: 0.45 m/s
(1.476 ft/s)

Rated drawbar pull

Max.: 65 kN

Min.: 23 kN

Gradeability

Max.: 35 %

Min.: 7 %

Rated output

46 kW, 165 kW
(62.5 hp, 224.3 hp)

Maximum operating pressure

19.5 MPa

Oil flow

100 l/min
(26.4 us gal/min)

Description

Hyster® Electric Big Forklift Trucks can power your possibilities by reducing emissions, fuel consumption, and helping lower maintenance costs while boosting performance and efficiency for intensive industries. Their exceptional traction power, acceleration, and visibility will make you feel like you’re driving a diesel. •Integrated lithium-ion power •Robust design •Operator comfort •Excellent visibility •Easily serviceable HIGH-PERFORMANCE, ZERO-EMISSION ALTERNATIVE INTEGRATED LITHIUM-ION POWER Hyster offers 350-volt lithium-ion solutions to deliver the big power, performance and uptime that operations need from their high-capacity big forklift trucks. Lithium-ion batteries produce higher performance throughout the charge cycle and have a longer life cycle, helping to reduce your total cost of ownership. Zero maintenance and fast charging times contribute to big savings and more uptime.
