Toe jack TL series

hydraulic2 ton10 tons

Overview

• Professional class
• Industrial, dual-purpose toe/head jack designed for lifting where minimum toe clearance is required or where a head lift is needed.
• Designed for house moving, machinery installation and applications at shipyards, bridge construction and plant sites.
• Compatible with machinery rollers for load transfer.
• 2001/2 swivel socket provided on 5 and 10 ton models for operation in any direction.
• Safety valve for overload protection.
• Spring-assisted return and over-travel protection on 5 and 10 ton models.
• Ram made of heat-treated special steel to resist corrosion and ensure strength.
• Operates in extreme temperatures.
• Pump handle included.
• Conforms to ANSI/ASME B30.1 standards.

Models and specifications
i-LIFT NO. | Model No. | Toe Capacity kg(lb.) | Head Capacity kg(lb.) | Min. Toe Height mm(in.) | Toe Lift mm(in.) | Max. Toe Height mm(in.)
2310901 | TL-7102 | 2000 (4400) | 3000 (6600) | 15.9 (0.6) | 112.7 (4.4) | 128.6 (5.1)
2310902 | TL-7105 | 5000 (11000) | 6000 (13200) | 22.2 (0.9) | 120.6 (4.8) | 141.3 (5.6)
2310903 | TL-7110 | 10000 (22000) | 14000 (30800) | 28.6 (1.1) | 146 (5.8) | 170.7 (6.7)

Technical features / specifications

• Series: TL SERIES
• Brand: i-LIFT
• Main features: industrial dual-purpose toe/head jack; safety valve for overload protection; spring-assisted return (5 and 10 ton models); over-travel protection (5 and 10 ton models); pump handle included; ram made of heat-treated special steel; suitable for extreme temperatures; conforms to ANSI/ASME B30.1.
• Model TL-7102 (i-LIFT No. 2310901): Toe capacity 2000 kg (4400 lb); Head capacity 3000 kg (6600 lb); Min. toe height 15.9 mm (0.6 in); Toe lift 112.7 mm (4.4 in); Max. toe height 128.6 mm (5.1 in).
• Model TL-7105 (i-LIFT No. 2310902): Toe capacity 5000 kg (11000 lb); Head capacity 6000 kg (13200 lb); Min. toe height 22.2 mm (0.9 in); Toe lift 120.6 mm (4.8 in); Max. toe height 141.3 mm (5.6 in).
• Model TL-7110 (i-LIFT No. 2310903): Toe capacity 10000 kg (22000 lb); Head capacity 14000 kg (30800 lb); Min. toe height 28.6 mm (1.1 in); Toe lift 146 mm (5.8 in); Max. toe height 170.7 mm (6.7 in).
