Floor jack HAS series

mechanical5 ton10 tons

Product overview
HAS series steel lifting jack with an adjustable lifting claw offering six positions. Designed for lifting a wide range of loads and for multiple lifting points. Optimized mechanical ratio reduces manual effort. Large base plate provides stability during lifting operations.

Models / Technical data

• HAS-3 — Safe working load 3000 kg (6600 lb); Height of load 720 mm (28.3 in); Lifting height 350 mm (13.8 in); Claw height in lowest position 69 mm (2.7 in); Net weight 25 kg (55 lb)
• HAS-5 — Safe working load 5000 kg (11000 lb); Height of load 720 mm (28.3 in); Lifting height 300 mm (11.8 in); Claw height in lowest position 64 mm (2.5 in); Net weight 30 kg (66 lb)
• HAS-10 — Safe working load 10000 kg (22000 lb); Height of load 792 mm (31.6 in); Lifting height 300 mm (11.8 in); Claw height in lowest position 85 mm (3.3 in); Net weight 48 kg (105.6 lb)
• HAS-15 — Safe working load 15000 kg (33000 lb); Height of load 805 mm (31.7 in); Lifting height 285 mm (11.2 in); Claw height in lowest position 120 mm (4.7 in); Net weight 63 kg (138.6 lb)

Specifications

• Series: HAS series
• Adjustable lifting claw with six positions
• Large base plate for improved stability
• Suitable for multiple lifting points and varied load types
• Optimized mechanical ratio for reduced force expenditure

Applications and ordering
Intended for industrial lifting tasks requiring compact, adjustable jacks for different load types and lifting points. For detailed dimensions, lifting accessories, certification information or spare parts availability, contact your supplier or sales representative.
