Cable pulling grip Mors à enroulement

Summary

• Capacity: Up to 20 kN
• Designed for tensile testing
• Sample alignment ensured
• Ideal for testing crimped terminations

Overview
Winding grips designed for tensile testing machines. Used to test rope, cable, filament, wires and other slender materials in tensile test applications. The systems incorporate a guide roller to limit failures inside the test fixture and ensure steady guidance of the specimen.

Operation
The fixtures feature a design that helps ensure correct sample alignment and promotes specimen failure between the upper and lower attachment points. The device includes a cylindrical bobbin around which the specimen is wound (typically 1-1/2 or 2 turns depending on material strength). Positioning on the bobbin allows force to be applied along the load cell axis.

Applications

• Tensile testing of ropes, cables, wires, filaments
• Testing of crimped connections and terminations
• Setups for tensile/compression test frames

Test standards
There are various test standards for ropes, filaments, cords, fine wires and cables. Appropriate test fixtures can be provided to meet the specific requirements of different test methods.

Features / technical specifications

• Type: Winding grips
• Rated capacity: Up to 20 kN
• Use: Tensile testing on testing machines
• Design: Cylindrical bobbin for specimen winding (1-1/2 or 2 turns depending on material)
• Additional elements: Guide roller to prevent internal failure and ensure steady specimen guidance
• Key functionality: Ensures sample alignment for correct failure between attachment points
• Typical applications: cable, rope, filament, wires, crimped terminations
