Single-phase electric energy meter EM613001

DIN railRS-485MID certified

EM series DC energy meters are designed for measuring and monitoring in DC systems. The din rail DC energy meters can measure of important DC parameters: Voltage, current, power and energy etc. It also support bi-directional measurement. All data in the meter are accessible via RS485 using Modbus RTU/DLT645. The meter working with DC power supply. Input voltage range up to 1000VDC, and current inputs are flexible with DC shunt. EM613001 is a DC din rail energy meter which can measure 10~240A, 40~400VDC. With shunt sampling, the accuracy is excellent, It also supports 4 tariffs and 8 slots, over/under-voltage alarm, over current alarm, event log, LCD display, FW upgrade, RS485 communication and DLT645 protocol. EM series dc meter is designed for scenarios such as DC panel, battery storage system, solar PV, EV charger and telecom base stations. Features Din Rail Mount; Shunt Sampling; Class 1 RS485 Communication with DLT645 Protocol Over-current/Over-voltage/Over-load Alarm Net metering for Renewable systems LCD Backlight; Multi-tariffs(RTC), Monthly Records Features Rate: Four Tariffs with 8 Time Slots Alarm function: over-voltage, over-current alarm, threshold can be set. Event record: The device itself stores the last 20 records when overvoltage, undervoltage, and overcurrent occur Display: LCD displays DC power, current, voltage, tariff power, data wheel display (time interval 5S), you can also turn pages by pressing an external button. Backlight: Press the page turning button to light up the backlight, which is convenient for viewing data when the light is insufficient
