Single-phase electric energy meter EM619001

DIN railRS-485with built-in communication

Product Details
There are 4 models of DC meter: EM613001/EM619001/EM619002/EM613005. EM series DC energy meters are designed for measuring and monitoring in DC systems. The DIN-rail DC meters measure key DC parameters: voltage, current, power and energy, and support bi-directional measurement. Data access is via RS485 (Modbus RTU / DLT645). Units accept AC/DC or DC power supply, input voltage up to 1000 VDC, and current via external shunt. Multi-tariff versions include RTC for tariff scheduling and monthly records.

Product Overview
EM619001 is intended for monitoring and control of DC installations, including PV string and battery systems. It supports limit alarms, analog output, digital input, relay output and communication functions. Provides energy metering, data processing, real-time monitoring and an LCD display. Designed for high overload capacity, accuracy, low consumption and automatic data save on power loss.

Product Parameters

• Reference voltage range: DC 5V–1000V
• Current measurement: up to 2000A (via shunt)
• Shunt signal input: 75 mV (max)
• Operating temperature: -25°C to +70°C
• Accuracy class: Class 1.0
• Relative humidity: up to 95% RH
• Communication: RS485
• Communication protocols: DLT645 / Modbus RTU
• Impulse constant: 1000 imp/kWh
• Display: 6+2 LCD with backlight
• Power consumption: ≤0.4W (≤8VA)

Main Features
RS485 communication for parameter setting and data reading (DLT645 / Modbus).
DC measurement via shunt sampling for high accuracy; measures DC voltage, current and power.
Alarm functions including over-current alarm with status register accessible via communication.
Backlit LCD showing energy, instantaneous parameters and status.
One-channel relay output for over-current cutoff. Firmware upgrade via RS485 local upgrade.

Technical Specifications

• Model: EM619001
• Mounting: DIN rail
• Voltage range: DC 5V–1000V
• Current input: up to 2000A (external shunt)
• Shunt input: 75 mV (max)
• Accuracy: Class 1.0
• Operating temperature: -25°C to +70°C
• Humidity: up to 95% RH
• Communication: RS485 (DLT645 / Modbus RTU)
• Display: 6+2 LCD with backlight
• Impulse constant: 1000 imp/kWh
• Power consumption: ≤0.4W, ≤8VA
• Functions: bi-directional energy measurement, alarms, analog output, digital input, relay output, RTC (multi-tariff version), firmware upgrade via RS485
