HDMI slip ring

gigabit EthernetHDMI-SDIHD-SDI

Product Description
With advances in technology and the expanding use of LED displays, rotating LED displays are increasingly deployed in large open venues. A conductive slip ring is a key component for rotating displays: it prevents cable tangling, enables 360° rotation with uninterrupted electrical conduction, and supports simultaneous transmission of power and multiple signal types.

Video & Signal Transmission
Ingiant provides slip rings configured for the high-definition video and high-speed data links required by rotating LED displays. Supported transmission options include:

• HDMI slip rings suitable for 4K video
• Gigabit Ethernet slip rings for network-based video/data
• High-speed broadband bus slip rings for VGA/HDMI signals
• SDI slip rings for HD video and high-speed digital signal transmission with EMC considerations

Applications

• Rotating LED displays for large venues and public installations
• Military visual and audio simulation systems
• Simulation and virtual reality systems (training, events)
• Telemedicine and remote visualization systems
• Educational and commercial display installations

Features

• 360° continuous rotation with maintained electrical conduction
• Simultaneous transmission of power and multiple signal types (video, audio, digital)
• Available high-definition and high-speed interfaces (HDMI, SDI, Gigabit Ethernet, VGA)
• Internal design for electromagnetic compatibility and reduced signal interference
• Customization options to meet specific customer video and signal requirements

Specifications / Technical Data

• Function: Prevent cable winding; enable 360° rotation with continuous conduction of power and signals
• HDMI support: High-definition HDMI slip rings suitable for 4K video
• Ethernet support: Gigabit Ethernet options for network-based video/data transmission
• SDI support: SDI slip rings for combined electrical, HD video and high-speed digital signals
• VGA/HDMI: High-speed broadband bus slip ring options
• Electromagnetic compatibility: Designed to meet EMC requirements and minimize interference
• Customization: Configurable to customer-specific video and signal transmission specifications
