Hydraulic fitting 078 seriesthreadedringbrass
Add to favorites
Compare this product
Characteristics
- Applications
- hydraulic
- Attachment
- threaded, ring
- Material
- brass, stainless, steel, nickel, NBR, medium
- Gender
- male, female
- Other characteristics
- high-flow, spring
- Diameter
23 mm
(0.906 in)- Operating pressure
35 bar
(507.63 psi)
Description
Our 078 series has a high flow performance. The safety lock system prevents un-intentional disconnection. To disconnect, the plug must first be pushed further into the coupling before it can be unlocked.
Advantages
High Flow Rates
Small Dimensions
Safety Locking System
Coupling Specifications
Back Body: Brass Nickel Plated
Valve Body: Brass Nickel Plated
Sleeve: Steel Nickel Plated
Spring and Locking Ring: Stainless Steel
Locking Balls: Stainless Steel
Seals: NBR
Plug Specifications
Plug Body: Steel Nickel Plated
Working Temperature (Depending on Medium):
-20°C to +100°C (NBR)
