Cone crusher H4e

stationarysecondarytertiary

Performance highlights Can be used in primairy, secondary, tertiary or quarternary crushing Designed to crush the toughest of rock and ore Feed size up to 185 mm (7”) C.S.S min. - max. 6 - 38 mm (2/10”-1 5/10”), depending on crushing chamber configuration Capacity up to 208 tonnes / hour Hopper 8 m³ (10 yard³) Other configurations possible with different crushing chambers Diesel / electric drive 2 speed track drive Optional pre screen 1.200 mm (4’) x 1.800 mm (6’) *not available in the United States Optional 3-deck screen 3.600 mm (12’) x 1.500 mm (5’) Effective screen area 5,4 m² on each deck, with return conveyor Best product shape Extensive option list to configure to your application Removable engine /generator compartment Specifications Transport dimensions Transport dimensions with after screen Working length without after screen Working length with after screen Weight - 35 t (38 sT) - 46 t (50 sT) - - Length - 14.475 mm (47’6”) - 18.500 mm (60’8”) - - 19.400 mm (63’8”) Height - 3.450 mm (11’4”) - 3.450 mm (11’4”) - 4.100 mm (13’5”) - 4.765 mm (15’8”) Width - 3.000 mm (9’10”) - 3.000 mm (9’10”) - 3.450 mm (11’4”) - 11.100 mm (32’10”)
