Swing check valve 164 02 seriesDINflangesafety
Add to favorites
Compare this product
Characteristics
- Type
- swing
- Connexion
- DIN
- Body
- flange
- Applications
- safety
- Material
- plastic, metal
- Valve plug seal material
- EPDM
- Other characteristics
- spring, seat
- DN
50 mm, 80 mm
(1.969 in, 3.15 in)- Pressure
16 bar
(232.1 psi)- Temperature
Max.: 100 °C
(212 °F)Min.: 0 °C
(32 °F)- Flow rate
64.7 m³/h, 130 m³/h
(2,284.86 ft³/h, 4,590.91 ft³/h)
Description
wetted metal parts made from dezincification-free and corrosion-resistant gunmetal, resistant against aggressive water
flange connection
with sidewise drain valve, rotatable hose connection element G 3/4
with test port
check valve with SST spring
EPDM-seat gasket
free from dead spots
for any installation position
alternative figure 137 02
Standards and Approvals
according to DVGW regulations
plastic parts with KTW and W 270 approval
according to accepted materials list from German environmental agency
acc. to DIN EN 13959 provisions / DIN EN 558-1
ÜA-Reg.-Nr. R-15.2.3-21-17048, WIEN-ZERT
