Diaphragm valve 141 0G serieshydraulicdistributiondrain
Add to favorites
Compare this product
Characteristics
- Type
- diaphragm
- Operation
- hydraulic
- Function
- distribution, drain
- Body
- male, seat, PTFE, metal
- Applications
- for pipe, parts
- Associated function
- balancing
- Other characteristics
- DIN, corrosion-resistant, thermal
- DN
15 mm, 20 mm, 25 mm
(0.591 in, 0.787 in, 0.984 in)- Pressure
16 bar
(232.1 psi)- Temperature
Max.: 90 °C
(194 °F)Min.: 50 °C
(122 °F)- Flow rate
1.3 m³/h, 1.6 m³/h, 3.2 m³/h
(45.91 ft³/h, 56.5 ft³/h, 113.01 ft³/h)
Description
thermostatic balancing valve for hydraulic balancing of riser and distribution pipes
for hydraulic balancing of hot water return systems (PWH-C), supports thermal disinfection
wetted metal parts made from dezincification-free and corrosion-resistant gunmetal, resistant against aggressive water
isolating unit with temperature sensor pocket
PTFE seat gasket
thermostatic balancing unit
male union thread
with plugged drain port
free from dead spots
with isolating, balancing and pre-setting function
Standards and Approvals
DVGW approval
ÖVGW approval
SVGW approval
WRAS approval
KIWA approval
plastic parts with KTW and W 270 approval
for systems according to DVGW worksheet W 551 / W 553 / DIN 1988-300
according to accepted materials list from German environmental agency
ÜA-Reg.-Nr. R-15.2.3-21-17048, WIEN-ZERT
