Diaphragm valve 150 6G seriesmanualhydraulicdrain
Add to favorites
Compare this product
Characteristics
- Type
- diaphragm
- Operation
- manual, hydraulic
- Function
- drain
- Body
- male, seat, PTFE, EPDM, metal, plastic
- Applications
- parts
- Associated function
- balancing
- Other characteristics
- DIN, corrosion-resistant
- DN
Min.: 15 mm
(0.591 in)Max.: 50 mm
(1.969 in)- Pressure
16 bar
(232.1 psi)- Temperature
Min.: 0 °C
(32 °F)Max.: 100 °C
(212 °F)- Flow rate
Min.: 4.48 m³/h
(158.21 ft³/h)Max.: 20.72 m³/h
(731.72 ft³/h)
Description
for hydraulic balancing of hot water return systems (PWH-C)
wetted metal parts made from dezincification-free and corrosion-resistant gunmetal, resistant against aggressive water
PTFE seat gasket
maintenance-free spindle gasket with self-lubricating EPDM lip gasket
male union thread
with plugged drain port
incl. thermometer
with pocket for temperature sensor Pt1000
free from dead spots
keeps throttle pre-setting when vale is closed and opened
with indicator for pre-setting
Standards and Approvals
DVGW approval
ÖVGW approval
SVGW approval
WRAS approval
KIWA approval
plastic parts with KTW and W 270 approval
for systems according to DVGW worksheet W 551 / W 553 / DIN 1988-300
according to accepted materials list from German environmental agency
DIN EN 1213
ÜA-Reg.-Nr. R-15.2.3-21-17048, WIEN-ZERT
