Automatic labeling machine Sistema TT

for tubes

This innovative solution was developed for the labelling of empty tubes mainly for the cosmetic and chemical sectors. The tubes are placed in the tube loader, separated and inserted on mandrels mounted on a carousel, which rotates and moves the products to the various operating stations. Label application is performed by a LABELX 140 ES and a product rotation system with automatic orientation of the label position respect to the cap opening. The support structure is made with the characteristic balcony construction with the electrical control panel located at the rear of the machine, and is equipped with polycarbonate guards. The system is managed by a PLC with Touch Screen operator interface. - LABELX 140 ES labelling machine - Horizontal and vertical micrometric adjustment unit with numeric position indicators - Empty tube feeding system with manual loading - Carousel transport module with 12-position jigs - Product rotation device - Automatic synchronisation of label dispensing speeds - MASTER support structure made of painted steel (stainless steel on request) - Total protection in transparent polycarbonate - Centralised electronics with Touch Screen operator panel and access for remote assistance - PLC unit with storage of operating parameters - Ind. 4.0 Ready - Speed up to 50 p/min (depending on product and label size) Optional accessories: - LABELX 250 ES - End-of-roll pre-alarm - Ultrasonic photocell for transparent labels - Black mark sensor detection for oriented label application
