Hydraulic oil COMPENSOL®

syntheticindustrialfor extreme conditions

Overview
COMPENSOL® by LEBEN-Dämpfungstechnik GmbH is a damping medium range developed for industrial shock absorbers. Available as hydraulic oil or a paste-like dispersion, formulations are offered for standard temperature ranges and for extreme conditions, with options for leak-free and fire-resistant configurations.

Designation
The commercial designation COMPENSOL® covers different consistencies supplied by LEBEN-Dämpfungstechnik GmbH, selected according to application requirements and operating temperature ranges.

Behaviour and special medium
For temperature-controlled indoor environments, COMPENSOL® is supplied as a fluid hydraulic oil. For applications above +80°C or below -40°C, a paste-like dispersion is used: at rest it appears solid, and under applied shear it flows. Once the load ceases, the material regains its initial solid-like state.

Properties of the dispersion

• Chemical: colloidal solid dispersion
• Physical / Rheology: non-Newtonian, shear-thinning Bingham fluid with viscoplastic and thixotropic behaviour

Detailed description
The paste-like medium forms a coagulated structure that deforms plastically under mechanical stress and rebuilds after unloading (thixotropy). Viscosity depends on shear stress: below a yield stress no flow occurs, above it the medium yields and flows. Depending on formulation, shear-thinning behaviour may commence immediately after yield or be preceded by a brief Newtonian plateau.

Applications

• Hydraulic damping for industrial shock absorbers and actuators
• Leak-proof damping solutions for machinery and safety-critical systems
• Fire-resistant damping where flame retardancy is required
• Viscosity control and tailored rheology for extreme temperature environments

Technical characteristics / specifications

• Commercial designation: COMPENSOL®
• Manufacturer / brand: LEBEN-Dämpfungstechnik GmbH
• Available consistencies: hydraulic oil (fluid) and paste-like dispersion for extreme temperatures
• Temperature suitability: standard ranges; paste-like dispersion for > +80°C or < -40°C
• Chemical nature: colloidal solid dispersion (for paste-like medium)
• Rheology: non-Newtonian, shear-thinning Bingham fluid with viscoplastic and thixotropic behaviour
• Functional behaviour: solid-like at rest, flows under applied shear (yield-stress behaviour)
• Key properties: leak-proof options, fire-resistant formulations, hydraulic damping medium
