TFT-LCD monitor 3205-A series

LED backlightfor digital signage32"

Overview
The Litemax 3205-A is a 32" color TFT-LCD display (Spanpixel series) with a 16:9 aspect ratio and 1920 x 1080 Full HD resolution. Engineered for high brightness (1000 cd/m²) and low power consumption, it integrates an efficient LED backlight and is suitable for sunlight-readable applications such as digital signage, public transportation, exhibition halls, department stores and vending machines.

Main features

• Triangle Display
• Brightness: 1000 nits (cd/m²)
• High color saturation: 94% (NTSC)
• Wide viewing angle: 178° (H), 178° (V)
• LED backlight
• Low power consumption
• Backlight MTBF: 100,000 hours
• High color depth: 16.7M display colors

Applications

• Digital signage
• Public transportation displays
• Exhibition halls
• Department stores
• Vending machines

Technical specifications

• Model Name: SSF3205-A / SSH3205-A / SSD3205-A
• Description: 32" TFT LCD, 1000 nits LED Backlight, 1920 x 1080, MaxRGB, Triangle Display
• Size: 32"
• Display area (mm): 676.53 (H) x 390.59 (V)
• Brightness: 1000 cd/m²
• Resolution: 1920 x 1080 (Full HD)
• Aspect ratio: 16:9
• Contrast ratio: 4700:1
• Pixel pitch (mm): 0.36375 (H) x 0.36375 (V)
• Pixel per inch (PPI): 69
• Viewing angle: 178° (H), 178° (V)
• Color saturation (NTSC): 94%
• Display colors: 16.7M
• Response time (Typical): 8 ms
• Panel interface: LVDS
• Input interface: HDMI, DisplayPort (DP)
• Input power: DC 12V
• Power consumption: model-dependent — 26W (one variant) and 42W (other variant)
• Dimensions (mm): 749.3 x 433.28 x 19.5 (one variant); 753.72 x 437.86 x 48.2 (other variant)
• Bezel size (U/B/L/R): 14 / 16.34 / 16.34 (one variant); 15.82 / 18.14 / 18.14 (other variant)
• Weight (Net): 2.8 kg (one variant); 3.7 kg (other variant)
• Mounting: 100 x 100 mm (VESA for one variant)
• OSD key: 4 keys (Power switch, Menu, +, -)
• OSD control: Brightness, Color, Contrast, Auto Tuning, H/V Position, etc.
• Operating temperature: 0°C ~ 50°C
• Storage temperature: -20°C ~ 60°C
