Ball valve V22 serieslevershut-off2-piece
Add to favorites
Compare this product
Characteristics
- Type
- ball
- Operation
- lever
- Function
- shut-off
- Body
- 2-piece
- Applications
- for industrial applications, for the chemical industry, for the petroleum industry
- Material
- stainless steel, cast steel, PTFE
- Other characteristics
- full-flow, anti-static, for corrosive environments, chemically inert, ATEX
- DN
Max.: 50.8 mm
(2 in)Min.: 6.35 mm
(0.25 in)- Pressure
Max.: 1,000 psi
Min.: 0 psi
- Temperature
Max.: 200 °C
(392 °F)Min.: -20 °C
(-4 °F)
Description
Product overview
A heavy-duty 2-piece full-bore ball valve manufactured in CF8M stainless steel with WCB body options and multiple seat materials. Designed for demanding process and chemical environments, the valve features a fully maintainable construction, ATEX approval and an anti-static device for safe use in hazardous areas.
Specifications
Design: 2-piece
Port: Full bore
Size range: 1/4" to 2"
Pressure rating: 1000 PSI max.
Body materials: CF8M / WCB
Seat materials: PTFE / RTFE
End connections: NPT, BSP, BSPT
Temperature range: -20°C to +200°C
Features
Applications
Technical specifications
A heavy-duty 2-piece full-bore ball valve manufactured in CF8M stainless steel with WCB body options and multiple seat materials. Designed for demanding process and chemical environments, the valve features a fully maintainable construction, ATEX approval and an anti-static device for safe use in hazardous areas.
Specifications
Design: 2-piece
Port: Full bore
Size range: 1/4" to 2"
Pressure rating: 1000 PSI max.
Body materials: CF8M / WCB
Seat materials: PTFE / RTFE
End connections: NPT, BSP, BSPT
Temperature range: -20°C to +200°C
Features
- Full port design for unrestricted flow
- Fully maintainable construction for onsite servicing
- ATEX approved for use in explosive atmospheres
- Anti-static device included
- Interchangeable seat options (PTFE / RTFE)
Applications
- Chemical processing plants
- Oil & gas pipelines and facilities
- General process industry
- Operation in classified / hazardous areas
Technical specifications
- Design: 2-piece construction
- Port type: Full bore
- Available sizes: 1/4" to 2"
- Maximum pressure rating: 1000 PSI
- Body materials: CF8M, WCB
- Seat materials: PTFE, RTFE (multiple options)
- End connections: NPT, BSP, BSPT
- Temperature range: -20°C to +200°C
- Certification: ATEX approved
- Safety: Anti-static device included
- Maintenance: Fully maintainable design
