LOW PERFORMANCE - Up to 30 operations a day on average
AUTOMATIC PAYOFF (Reference position [1] on technical data sheet): drum diameter range Ø800mm to Ø2600mm, drum width range 400mm to 1480mm, pulling with adjustable automatic hydraulic tensioning min. 15kg, max. 100kg
AUTOMATIC TAKE-UP (Reference position [2] on technical data sheet): drum diameter range Ø800mm to Ø2600mm, drum width range 400mm to 1480mm, winding motor power 22kW
Automatic layering with LASER alignment sensors (Reference position [12] on technical data sheet)
Automatic cable diameter measuring (Reference position [3] on technical data sheet)
Measuring device with horizontal and vertical cable guide rollers automatic opening and closing, for cable min. Ø5mm max. Ø100mm, tolerance ±0.5% for cable min. Ø10mm max. Ø80mm (Reference position [3] on technical data sheet)
Automatic drum data settings
Automatic tensioning adjustment based on cable diameter with hydraulic tensioning brake ON PAYOFF, tension sensitivity min. 15kg, max. 100kg (Reference position [5B] on technical data sheet)
Coiling head built into arm, with manual cable attachment, collapsible coiling head with manual opening of coil-retaining spokes, Ø1000mm width 90 to 200mm internal core 320mm fixed (option of 520mm fixed) (Reference position [6B] on technical data sheet)
Winding head for spools min. Ø100mm max. Ø500mm (Reference position [4] on technical data sheet)
Automatic three-stage roller conveyors with front loading (Reference position [7] on technical data sheet)
Automatic drum bore height detection laser barrier (Reference position [13] on technical data sheet)
