Water pump MACROY®
acidoilelectric

water pump
water pump
Add to favorites
Compare this product


Characteristics

Fluid
water, acid, oil
Operation
electric
Technology
diaphragm
Mobility
stationary
Domain
industrial, for water treatment
Applications
metering, process, treatment, adjustment
Material
aluminum, plastic
Other characteristics
compact, mechanically-actuated, high-efficiency, heavy-duty, rugged, high-flow, low-pressure, corrosion-resistant, rugged
Flow

1,181 l/h
(311.98719 us gal/h)

Pressure

12 bar
(174.045 psi)

Description

Simple. Rugged. Smart. Efficient design for low-pressure, high-output water treatment applications now NSF/ANSI 61 and 372 certified. The G series metering pump, also known as the MACROY® pump, is now NSF/ANSI 61 and 372 certified for municipal compliance and safety assurance. Capable of handling pressures up to 175 psi (12 bar) and flow rates up to 310 gph (1181 l/h) it is an ideal pump for water treatment applications. Combining heavy-duty industrial drive technology with state-of-the art design and manufacturing processes, this mechanically-actuated diaphragm pump eliminates flow restrictions, reduces the possibility of hydraulic oil contamination of process liquid, and ensures smooth output. All models are not available in all locations. Check with your local representative for details. Simplicity of design. The pump has few moving parts and is compact and lightweight. Greater flexibility. G series pumps feature a variable eccentric drive with stroke adjustment. It is available in three frame sizes and can accommodate a wide selection of liquid ends. Rugged performance. Corrosion-resistant plastic or aluminum housing is designed to withstand tough environments while its high-efficiency motors minimize heat buildup. Long-term cost benefits. This reliable pumps requires minimal maintenance, reducing overall pump lifecycle costs. Now NSF / ANSI 61 and 372 certified for municipal compliance and safety assurance
