Track guide rail RMG-1
Add to favorites
Compare this product
Characteristics
- Applications
- for track
Description
Product overview
Description
Side guides are used to help locate workpieces laterally during loading relative to the clamping force, either manually or using a spring guide. This side guide type can remain in position during machining, or be removed or flipped down when the workpiece side must be accessible for machining. RMG-M1 is a pre-assembled combination of side guide RMG-1 and magnet M-1.
Details (table)
Type | Weight approx. (g) | Dimensions | STEP (3D)
RMG-1 | 110 | PDF drawing available | STEP (3D) file available
Technical specifications
- Multi-Rail RM
- Multi-Rail System
- RM side guides
- Side guides
- System components
Description
Side guides are used to help locate workpieces laterally during loading relative to the clamping force, either manually or using a spring guide. This side guide type can remain in position during machining, or be removed or flipped down when the workpiece side must be accessible for machining. RMG-M1 is a pre-assembled combination of side guide RMG-1 and magnet M-1.
Details (table)
Type | Weight approx. (g) | Dimensions | STEP (3D)
RMG-1 | 110 | PDF drawing available | STEP (3D) file available
Technical specifications
- Type: RMG-1
- Weight approx.: 110 g
- Combination: RMG-M1 = side guide RMG-1 + magnet M-1
- Function: locates workpieces sideways during loading (manual or with spring guide)
- Installation/usage: can be kept in place while machining or removed/flipped down to free the workpiece side for machining
- Product categories: Multi-Rail RM; Multi-Rail System; RM side guides; Side guides; System components
Catalogs
Multi-Rail RM System
20 Pages
