Hydraulic piston pump P820 series

air-drivenATEXdouble-acting

The high performance pneumohydraulic pump incorporates a double-acting pneumatic motor. The pump operates on compressed air with 2 to 7 bar pressure for construction of circuits that demand high oil delivery rates at medium-low pressures. The compact in-built pump is suitable for mounting vertically or horizontally for easy installation in fixed or mobile units. The unit is constructed with 5 intensification ratios to achieve up to 280 bar and deliver up to 22 litres/min. The standard version comes with about 2 litres capacity tank based on the model and mounting position and offers a distribution manifold with delivery line and return line. The pumps includes accessories such as various capacities tank, CETOP3 distribution manifold, pneumatic system accessories and hydraulic system accessories
