Refrigerated compressed air dryer COM-DRY series
heat-of-compressionhigh-qualitymedium-size

refrigerated compressed air dryer
refrigerated compressed air dryer
refrigerated compressed air dryer
Add to favorites
Compare this product


Characteristics

Technology
refrigerated, heat-of-compression
Other characteristics
high-quality, medium-size
Capacity

Min.: 6 m³/h (211.89 ft³/h)

Max.: 6,500 m³/h (229,545.33 ft³/h)

Working pressure

Min.: 4 bar (58.015 psi)

Max.: 14 bar (203.053 psi)

Description

COM-Dry dryers have been designed for continuous separation of water vapour from compressed air thus reducing dew point. Drying consist of two steps. Refrigerant dryer first eliminates large majority of water and reduces dew point down to PDP +3°C. Further reduction of dew point is carried out by adsorption dryer. Operation of dryer is more simple compared to conventional heat regenerated adsorption dryer while average compressed air losses present only up to 4,6 %. Characteristics: - operating presure: 4 - 14 bar - operating temperature range: 1,5 °C to 55 °C - pressure dew points: down to -40 °C - flow rate: 6 to 6.500 Nm³/h - average compressed air consumption: 4,6 % Applications: - compressed air systems
