Electric actuator DR Serieslinearstepperball screw
Add to favorites
Compare this product
Characteristics
- Type
- electric
- Movement
- linear
- Technology
- stepper, ball screw
- Motor
- DC
- Applications
- for process automation
- Other characteristics
- compact, motorized, integrated, lightweight, flange-mounted, with brake, with sensor option
- Stroke
30 mm
(1.181 in)- Force
40 N
- Speed
Min.: 40 m/s
(131.23 ft/s)Max.: 100 m/s
(328.08 ft/s)
Description
Compact linear actuators with absolute encoder for DC power supply
DR series
Features
Battery-free absolute sensor
No external sensors required
Compact and lightweight
EtherCAT, EtherNet/IP, Profinet, Modbus RTU
Frame size: 28 x 28 to 66 x 28.5 mm
Thrust: 20 - 40 N
Push force: 50 N
Max. speed: 40 - 100 mm/s
Max. Transport load: 0 - 4 kg
Options: Spindle protection, mounting flange, mounting foot
