Friability testing device PTF 600
abrasionautomatedtablet

friability testing device
friability testing device
friability testing device
friability testing device
friability testing device
friability testing device
Add to favorites
Compare this product


Characteristics

Test type
abrasion, friability
Operating mode
automated
Test material
tablet
Sector
for laboratories
Technology
digital

Description

PTF 600 is a six drum tablet friability and abrasion test instrument. It is manufactured in compliance to the USP , EP and JP Pharmacopoeias. The instrument features an automated sample discharge at the end of a test and the possibility to connect an analytical balance. Complete Compliance One of the testing criteria for mechanical strength of tablets and cores according to the USP , EP , JP and other pharmacopoeia is friability and abrasion testing. During the process of coating, transportation and packing the tablet will lose some amount of weight. To measure this weight loss, the samples are counted and weighed. Then the friability test is performed following the individual monographs of the relevant Pharmacopoeia. The tablets are tumbled at each turn of the drum of the friability testing instrument by a curved baffle that extends from the middle of the drum to the outer wall. Automated Discharge Clean the samples from any dust prior to the test. Weigh the samples and introduce them into any drum of the instrument. The drums can easily be opened for loading and cleaning. Alternatively it is possible to use the discharge opening to load the samples without opening the drum. Select a test method and start the run. The LCD with color-changing backlight shows the test status and results.
