Pneumatic fitting MICRO-RAP series
push-inbrasscompact

pneumatic fitting
pneumatic fitting
pneumatic fitting
pneumatic fitting
pneumatic fitting
Add to favorites
Compare this product


Characteristics

Applications
pneumatic
Attachment
push-in
Material
brass
Other characteristics
compact
Diameter

Min.: 2 mm (0.079 in)

Max.: 4 mm (0.157 in)

Operating pressure

10 bar (145.04 psi)

Description

MICRO-RAP SERIES, COMPACT PUSH-IN FITTINGS "Micro-RAP" Series, compact push-in fittings Micro-RAP Series, Compact brass push-in fitting PNEUMAX "MINI" SERIES TECHNICAL SHEET The MINI supercompact fittings sériés, extremely lightweight yet sturdy, can be inserted and extracted with one hand and it is suitable for tube PA, TPU, Ny and PE. The O-Ring is provided with his own seat to ensure seal with polished surface. FLUIDS Compressed air (for different fluid pis contact Pneumax Technical Dept.) APPLICATIONS Pneumatic circuits, also suitable for vacuum apllication WORKING TEMPERATURE -20° C +70° C MAXIMUM WORKING PRESSURE 10 bar THREAD TYPE Cylindrical with O-ring MAXIMUM TORQUE Thread M3 = 0,4 Nm Thread M6 and M6x0,75 = 1,3 Nm MATERIALS Nichel-plated brass body UNI EN 12164 CW614N Brass gnp Silicon free NBR gaskets
