Sliding door RC2

steelglassglazed

Overview
A burglar‑resistant automatic sliding door engineered to combine the aesthetic and functional qualities of glazed automatic entrances with RC2 resistance performance (UNE‑EN 1627:2021). Modular design allows adaptation to multiple opening configurations and project requirements.

Security reinforcements

• Top and bottom leaf guidance with anti‑leverage reinforcements preventing removal of leaves from the guides.
• Motorized multipoint locking system developed with Manusa technology.
• Anti‑leverage steel shield protecting and enclosing the high‑security cylinder.
• Reinforced side closure edges to prevent manipulation of door leaves.
• Locking operation configurable for automatic or manual locking/unlocking from both interior and exterior for site safety and user protection.

Safety glass options

• P5A glass with air chamber: two laminated glass units separated by a dehydrated air chamber; maximizes resistance to intrusion attempts while improving thermal and acoustic insulation. Glass layers remain bonded on impact.
• P4A glass: laminated assembly with multiple PVB interlayers providing high tear resistance; maintains integrity if broken and acts as an effective security barrier.

Operational & performance features

• Operates as a fully automatic sliding door while providing RC2‑level resistance without requiring an additional shutter closure.
• Contributes to energy efficiency by remaining closed when not in use, helping maintain interior climate control.
• Connectivity: compatible with Doorwifi application for remote status monitoring, scheduling and remote management.

Compliance & testing
Tested to resistance class RC2 according to UNE‑EN 1627:2021; designed to ensure attempted intrusions remain within the resistance objectives defined for RC2.

Applications

• Retail (supermarkets, high‑traffic commercial entrances)
• Banks and financial institutions
• Airports, hotels and commercial premises requiring asset protection without losing glazed entrance aesthetics

Technical specifications

• Resistance class: RC2 (UNE‑EN 1627:2021)
• Supported door types: central opening, lateral opening; 1, 2 or 4 leaves; with or without fixed side panels (modular configurations)
• Reinforcements: anti‑leverage guides (top/bottom), reinforced lateral closure edges, anti‑leverage steel cylinder shield
• Locking: motorized multipoint lock (Manusa technology); automatic or manual locking/unlocking interior & exterior
• Glass options: P5A (laminated units with air chamber) and P4A (laminated with multiple PVB interlayers)
• Energy & insulation: improved thermal and acoustic performance with specified glazing
• Connectivity: Doorwifi compatible for remote management and monitoring
• Design: modular for customization to project requirements
