PVC floor tile H5 Series

recycled plasticanti-slipanti-static

Overview
Heavy‑duty Ergo Advantage modular tile system designed for static‑sensitive industrial workstations and harsh dry environments. Configurable layout with interlocking 46 cm × 46 cm tiles for fast installation and reconfiguration.

Key features

• Dissipative ESD construction to protect tools and personnel from electrostatic discharge.
• 64‑point support structure for even load distribution and integrated cable routing.

Performance attributes

• Cushioning: Medium
• Pressure distribution: Ultimate
• Bounce‑back: Ultimate
• Top surface grip: High
• Floor grip: High

Recommended use
Optimised for demanding dry areas with occasional exposure to industrial fluids.

• ESD‑sensitive industrial environments
• Electronics manufacturing and assembly lines
• Technical workstations with cabling and equipment
• Welding and fabrication stations

Ergonomic guidance

• Suitable for prolonged standing up to full shifts
• Designed for use by operators of all sizes

Available configurations

• 46 cm × 46 cm modular tiles, extendable and reconfigurable
• Yellow and black safety ramps available
• Fully connectable with other H‑Series products
• Optional protective underlay accessory for installation over metal grating

Origin
Made in the UK

Technical specifications

• Material: 100% Recycled PVC with Embedded ESD Polymer
• Fire rating: Efl – s2
• ESD rating: 1.3 x 10 Ω
• Max load capacity: 1 t/m² point load | recommended max. rolling load: 300 kg
• Moisture resistance: High
• Oil resistance: High
• Chemical resistance: High
• Recyclable: Yes
• REACH: Yes
• Phthalate‑free: Yes
