Absolute linear encoder RESOLUTE™ RSLA30

opticalnon-contactIP64

What is RESOLUTE? RESOLUTE is a true absolute, fine pitch optical encoder system that has excellent dirt immunity, and an impressive specification that breaks new ground in position feedback. It is the world's first absolute encoder capable of 1 nm resolution up to 100 m/s. Ultra low SDE and jitter result in a linear encoder system that outperforms any other encoder in its class. What is RSLA30 scale? RSLA30 is a stainless steel spar scale featuring our 30 µm pitch absolute scale code. It is comparable to fine pitch glass scales and offers a total accuracy (including slope and linearity) better than ±4 µm over a 5 m length. It can also be coiled for simple storage and handling yet once uncoiled behaves as a spar scale. System designers can choose between specially formulated adhesive tape or mechanical clips to suit mounting requirements. Both mounting methods allow for independent thermal expansion to that of the substrate.
