DC electromechanical relay YT-525

auxiliarylatching

Product description
YT-525 changes the direction of air flow from one output port to another when it senses low or abnormal air pressure. Designed as an accessory for valve positioners, it enables controlled switching and actuator locking.

Features

• Automatically switches pressure flow when low or abnormal pressure is detected
• Ability to lock the actuator in its current position
• Stem can be extended and connected to remote mechanisms

Range
YTC - Valve Positioner Accessories

Downloads (available documents)

• PUB126-106 - YT-520_525_530_535 - Manual - English (pdf)
• YT-525D Valve accessories 2D Drawing_YT525D-1rev3_1224 (pdf)
• YT-525S Valve accessories 2D Drawing_YT525S-1rev3_1224 (pdf)

Technical specifications

• Brand: YTC
• Commercial model: YT-525
• Function: Changes direction of air flow between output ports when low or abnormal air pressure is detected
• Feature: Can lock actuator in its position
• Feature: Stem extension and connection capability
• Product family / range: YTC - Valve Positioner Accessories
• Available documentation: product manual (PUB126-106 - YT-520_525_530_535 - Manual - English) and 2D drawing files for YT-525 (D and S variants)
