Reverse pneumatic relay YT-535

lock

Product Description
YT-535 is a pneumatic snap-acting relay that switches the direction of air flow between output ports when low air pressure is detected. It is designed to interface with actuators and to hold or change actuator position as required.

Features

• Automatically switches pressure flows when abnormal or low pressure is detected
• Provides actuator locking capability to hold position
• Extendable stem for connection to actuator mechanisms

Range
YTC - Valve Positioner Accessories

Documentation (filenames)

• PUB126-106 - YT-520_525_530_535 - Manual - English (pdf)
• YT-535D Valve accessories 2D Drawing_YT535D-1rev3_1224 (pdf)
• YT-535S Valve accessories 2D Drawing_YT535S-1rev3_1224 (pdf)

Technical specifications

• Brand: YTC
• Model: YT-535
• Commercial name: YT-535 - Snap acting relay
• Function: changes the direction of air flow rate from one output port to another when low air pressure is sensed
• Switching behaviour: switches pressure flows when abnormal pressure detected
• Mechanical: stem can be extended and connected
• Actuator interface: able to lock actuator in its position
